Reman. EL850 4-Hole Base Mount

• Rotatable Head
• Belt Drive
• End Cap Oil Feed
• Base Oil Drain
• Overall Height: 11.00 in.
• Overall Width: 4.78 in.
• Overall Length: 10.08 in.
• External Shaft Length: 2.22 in.
• Approximate Weight: 23 lbs.
• Torque Nut to 80-100 ft. lbs.

Notes

1. Port orientation viewed from front.
2. Changeover/Installation Instructions - L31043
3. Service/Repair Instructions For Cylinder Head - L31059.
4. Service Units are furnished without governors and manifolds and may require head rotation before installation or changeover.
5. Thru-drive units must not exceed 65 ft. lbs. of transmitted torque.
