EL1300 DDC Compressor

Part no. EL13100X
item status Active
Product line Reman
Remanufactured Detroit Diesel 50°
  • Head Rotatable
  • Flange Mount, Gear Drive
  • Top/Flange Discharge Type
  • End Cap Oil Feed
  • Flange Oil Drain
  • Water Cooled
  • Overall Height: 12.00 in.
  • Overall Width: 7.09 in.
  • Overall Length: 9.90 in.
  • External Shaft Length: .41 in.
  • Approximate Weight: 49 lbs.
Notes
  1. Orientation viewed from front.
  2. Service units are furnished without governors and manifolds and may require head rotation and end cap rotation before installation or changeover.
  3. Typical - Torque Nut to 100 - 135 ft. lbs.
  4. Include Installation Gaskets
Availability
USA
Call for Availability Tel: 1-800-643-2374
Canada
Call for Availability Tel: 1-800-267-9247
blobid0.png WARNING
Cancer and
Reproductive Harm
www.P65Warnings.ca.gov

Technical specs

Head Rotation Right
Block Rotation Right
Application DDC 50° Engines
Notes High capacity replacement EL16100X
OEM Part Number N7010 Exact Replacement
Core Group 1300
Overall Height 12.00 in. (EL1300), 12.19 in. (EL1600)
Overall Width 7.09 in.
Overall Length 9.90 in.
External Shaft Length .41 in.
Bore Diameter 2.75 in.
Stroke 1.50 in. (EL1300) and 1.87 in. (EL1600)
Rated Displacement 13.0 (EL1300) and 16.1 (EL1600) CFM @ 1250 RPM
Approximate Weight 49 lbs.
