EL850 Like Nu™Compressor

Referencia KN85020X

item status Active

Product line Reman

ADVERTENCIA

Cáncer y
Daños reproductivos
www.P65Warnings.ca.gov

Print this page

Especificaciones técnicas

Intake Manifold Position	Right
Application	Air Cooled , Single Cylinder
Discharge Type	Front-Threaded
OEM Part Number	N7502 Exact Replacement
Overall Height	11.00 in
Core Group	850
Overall Width	4.78 in.
Overall Length	10.08 in.
External Shaft Length	2.22 in.
Bore Diameter	3.15 in.
Stroke	1.50 in.
Rated Displacement	8.5 CFM @ 1250 RPM
Approximate Weight	24 lbs.
