Brake Chamber for drum brake
This table shows Haldex brake chambers for drum brake applications. Both LifeSeal (SOP 2021) and Blue Seal range are listed with Xref (cross-references) for easy comparison. This list applies to both OE and AM applications.
Manufacturers will find drawings (CAD and 3D) as well as Annex 19 Test report for Vehicle Type Approval. Distributors and workshops can compare the variants and find a suitable application, using for example the port orientation information. Some applications have fixed orientation
| Type | Part number | Stroke | Port / Orientation | Mounting nuts | Pushrod Length | Yoke | Protection | Xref | TÜV Report | CAD | 3D |
| 9 | 123 090 001 | 60 | M16 / 0° Adj. | Y | 185 | N | Disc | - | BC0094.1 |  |
 |
| 123 090 004 | 60 | M16 / 0° Adj. | Y | 90 | N | Disc | - | ||||
| 12 | 123 120 001 | 57 | M16 / 0° Adj. + Central | Y | 186 | N | Disc | - | BC0095.1 | |
|
| 123 120 002 | 57 | M16 / 0° Adj. + Central | Y | 186 | N | Boot | - | |
|
||
| 16 | 123 160 001 | 75 | M16 / 0° Adj. + Central | Y | 186 | N | Disc | - | BC0096.1 | |
|
| 123 160 002 | 75 | M16 / 0° Adj. + Central | Y | 186 | N | Boot | - | |
|||
| 20 | 123 200 001 | 75 | M16 / 0° Adj. + Central | Y | 186 | N | Disc | - | BC0097.1 | |
|
| 123 200 002 | 75 | M16 / 0° Adj. + Central | Y | 186 | N | Boot | - | |
|||
| 123 200 003 | 75 | M16 / 0° Adj. + Central | Y | 210 | N | Disc | - | |
|||
| 24 | 123 240 001 | 75 | M16 / 0° Adj. + Central | Y | 186 | N | Disc | - | BC0098.1 | |
|
| 123 240 002 | 75 | M16 / 0° Adj. + Central | Y | 186 | N | Boot | - | |
|||
| 123 240 003 | 75 | M16 / 0° Adj. + Central | Y | 210 | N | Disc | - | |
|||
| 123 240 004 | 75 | M16 / 0° Adj. + Central | Y | 146 | N | Disc | 123 240 001 | |
|||
| 127 240 401 | 76 | M16 / 0° Adj. | N | 236 (incl. Yoke) |
Y | Disc | - | |
- | ||
| 30 | 123 300 001 | 75 | M16 / 0° Adj. + Central | Y | 186 | N | Disc | - | BC0099.1 | |
|
| 123 300 002 | 75 | M16 / 0° Adj. + Central | Y | 186 | N | Boot | - | |
|||
| 123 300 003 | 75 | M16 / 0° Adj. + Central | Y | 210 | N | Disc | - | |
|||
| 120 366 201 | 80 | M16 / 0° Adj. + Central | Y | 187 | N | Disc | - | |
|
||
| 36 | 123 360 004 | 75 | M16 / 0° Adj. + Central | Y | 60 | N | Disc | 120 376 102 | BC0100.1 | - | - |
| 120 376 102 | 75 | M16 / 0° Adj. + Central | Y | 192 | N | Boot | - | |
|
